Over the past year the notebook industry has grown by a lot, but we can think of no single organization that has shown as a lot individual growth as Asus. Asus notebooks have traditionally been regarded as high high quality, but they merely weren’t as widely known by consumers. Even less known was the fact that Asus makes many of the ODM models major manufacturers buy and brand as their own. With Asus-branded notebook shipments growing and a recent design win with Dell, Asus is in route to the peak and is a formidable player in the notebook industry.
The Asus A7G is really a 17′ widescreen ‘multimedia notebook’ as described by Asus, and is one sleek package. Design has always been top notch with Asus and also the A7G’s sleek two-tone scheme is sophisticated, yet not too flashy. Our test model came nicely loaded with a speedy Pentium M 760 (2.0GHz), 1GB DDR2 533 RAM, 100GB 5400RPM Difficult Drive, a built-in TV tuner, and lastly ATI’s fresh new Mobility Radeon X1600 GPU. The A7G is well built, continuing the quality shown by all the Asus notebooks we’ve come across. When you first open up the A7G, you could be taken aback by its large size. We feel that the layout from the A7G wasn’t really optimized for size, as there is a fair amount of screen bezel along with a large chassis area around the keyboard making it seem rather bloated. Whilst it’s understandable that Asus didn’t want or need to make the A7G slimmer or sleeker, it certain would be appreciated by most users.
The 17′ WXGA (1440×900) ColorShine display is unsurprisingly, breathtaking. The colors are extremely bright and vivid, thanks to both Asus’ Splendid Video color enhancement software and ATI’s AVIVO technology in the Mobility Radeon X1600. The brand spanking new ATI Mobility Radeon X1600 is featured only in the Asus A7G during the time of writing, and is undoubtedly the greatest GPU for a thin & light performance application. Now the A7G isn’t exactly thin or light, making us wish ATI had included a higher end GPU for gaming; candidates could have included the NVIDIA GeForce Go 7800GTX or ATI’s somewhat outdated Mobility Radeon X800XT. As much as we love the style and the screen, Asus could have included a little punchier speakers being a multimedia machine and a more powerful GPU would certainly have been welcomed by gamers. A higher resolution screen option is noticeably absent, but we imagine that higher resolution panels would sacrifice the caliber of this ‘low resolution’ WXGA display. Overall the A7G is really a solid, nicely built, feature filled, and powerful machine; it is simply too bad it isn’t available within the U.S., yet. Across the sea MSRP for this beast is The 17″ WXGA (1440×900) ColorShine display is understandably, breathtaking. The colors are extremely bright and vivid, thanks to both Asus Splendid Video color enhancement software and ATIs AVIVO technology within the Mobility Radeon X1600. The brand spanking new ATI Mobility Radeon X1600 is featured only within the Asus A7G during the time of writing, and is without a doubt the greatest GPU for a thin & light performance application. Now the A7G isnt exactly thin or light, making us wish ATI had included a higher end GPU for gaming; candidates could have included the NVIDIA GeForce Go 7800GTX or ATIs somewhat outdated Mobility Radeon X800XT. Around we love the style and also the screen, Asus could have included a little punchier speakers being a multimedia machine and a more powerful GPU would certainly have been welcomed by gamers. A higher resolution screen option is noticeably absent, but we imagine that higher resolution panels would sacrifice the grade of this low resolution WXGA display. Overall the A7G is a solid, nicely built, feature filled, and powerful machine; it is just too bad it isnt available in the U.S., yet. Across the sea MSRP for this beast is 1399, or roughly $2200USD. The price is certainly on the high end, and for that a lot we would appreciate a more powerful GPU and 7200RPM difficult drive, but the multimedia features are all there and they pack quite a punch.
The only 17 notebook weve seen that is remotely portable was Dells Inspiron 9300, and the A7G isnt nearly as petite as the 9300. Measuring a hefty 15.9 wide, 12.3 deep, and 1.5 thick, Asus A7G isnt destined to be a machine you want to take everywhere you go. The bezel around the LCD might be smaller to allow for a smaller chassis, but you would then lose the camera and middle speaker. The only portability we recommend with this machine is moving it around your living room.
Weve always loved the style and design of Asus notebooks, and also the A7G is no exception. The sleek two-tone chassis is stylish and hip. Youll notice the hinge is composed of a relatively small cylinder, but the LCD has a very secure attachment towards the hinge cylinder and feels very solid. Since the A7G is multimedia oriented, the media control buttons are accessible even with the LCD closed.
Examining the interior, we see the simple two-tone color scheme and striking blue LEDs. The layout is standard, with several buttons and LEDs at the pinnacle. From left to right you have Bluetooth and Difficult Drive Activity LEDs. There is also probably a WiFi indicator, but our model did not have WiFi enabled so we were unable to verify this. You also have several buttons consisting of Power4Gear, Internet Browser, E-Mail, and Touchpad Disable from left to right. The Power4Gear button cycles through Asus excellent power management profiles with an on screen indicator in the upper left hand corner. We feel that the LEDs at the top has been larger and brighter. Whilst we appreciate the simple look, they are difficult to view from a distance and it isnt easy to decipher what the LED actually indicates.
The A7Gs keyboard is full size, but looking at it when compared with the chassis makes it seem diminutive. Just looking at it, one might wish the keyboard was larger and also the speakers on either side smaller. However, after sitting down and typing at it for a while, the size feels quite natural and comfortable. When placing your hands to start typing, the big palm rest area supports ones hands well and contributes to an overall good typing experience.
The travel distance and quality of the keys themselves was excellent as well. Whilst we cant say this is of Thinkpad or Powerbook high quality, no one should be disappointed. The function keys available are a fairly standard load. From left to right you have Sleep (F1), wireless radio control (F2), Brightness Down (F5), Brightness Up (F6), LCD Off (F7), Display Output (F8), Mute (F10), Volume Down (F11), and Volume Up (F12). All of these buttons activate an On Screen Display in the upper left hand corner, showing you the relevant information for the selected function. The wireless radio control button can be configured to toggle one or all the wireless radios (i.e. Bluetooth and/or WiFi).
It is a little difficult to comment on key placement here, as this model is not intended for sale within the U.S. (presently). Speaking purely from a standard U.S. keyboard layout, this keyboard is atrocious. The left shift key is tiny and also the Enter key is abnormally shaped. I cant speak for other people, but when I place my hands on a keyboard I use the left shift key as a placeholder to get the rest of my fingers aligned properly. That is pretty much impossible on this machine! We hope against all odds that this keyboard will not find its way into any potential U.S. models, as weve not seen a keyboard like it from other companies. However, on the upside, the Russian characters are pretty to look at.
Asus chose to include a standard touchpad with two buttons and scrolling regions. It’s a little larger than most touchpads which is nice, and is responsive as any. The buttons don’t have a deep travel depth, instead having a very shallow and sharp click. You actually have to click them more towards the middle of the two buttons, as the outside edge of each button is apart of the frame around the touchpad. The inside area of each button are what actually clicks, so it takes a little becoming familiar with but is not a huge nuisance.
We see a large number of ports on the rear from the A7G, which fits in with its DTR design. People who use a notebook as desktop replacement would prefer more of their ports on the back, as they have to plug/unplug devices less often. From left to right, we see the exhaust port, S-Video Out, VGA out, Parallel, and four USB 2. ports. The Parallel port is a surprise, although a welcome one. Not many people use parallel devices, like older printers, these days, but it cant hurt to have one. The plethora of USB ports on the back is also an excellent choice, ensuring users are able to plug in the numerous USB devices out there today.
Desktop replacement notebooks generall trend 1 of 2 ways: either with a cool & quiet cooling system or they just run blatantly warm. The A7G’s CPU runs fairly cool, staying around 40 degrees Celcius when idle at 800MHz. With the CPU spiking to 2GHz or even idling at 2GHz, temperatures will quickly rise to 50 C and above. This isn’t an issue for concern, just somewhat disappointing as possible feel several warm spots on the underside from the A7G. What is somewhat concerning is the hard drive temperature. In this chassis the Fujitsu difficult drive stays within the upper 30 degrees C, breaking 40 C fairly easily. This is likely not a sign from the hard drive itself producing heat, but heat from the rest of the system not being dissipated properly.
The A7G uses Intels latest Pentium M platform, codenamed Sonoma. As most of you know, this update towards the popular technology brings a faster front side bus, PCI Express, High Definition Audio, Serial ATA, DDR2 RAM, and more. Our model came loaded with the Pentium M 760, running at 2.0GHz with 2MB L2 Cache on a 533MHz FSB. The Intel 915PM chipset is used, providing discrete graphics via ATI’s brand new Mobility Radeon X1600. The higher bus speeds help improve performance as does the faster RAM running synchronous with the FSB. DDR2 is also Dual Channel capable, meaning that using two identical memory modules effectively doubles your memory bandwidth.
This notebook is the first of its kind, implementing ATIs new GPU: the Mobility Radeon X1600. Unlike the previous X600/X700 models which were near identical to the 9000 series, the X1000 series GPUs are an entirely new architecture. We will go into more detail in an upcoming gaming article about this new GPU, but lets cover the basics here. The Mobility Radeon (MR) X1600 is built on a 90nm manufacturing process, which brings smaller die sizes, lower power consumption, and potentially higher clock scaling. The architecture driving the X1600 is equivalent to its desktop brethren, bringing with it higher performance, a greater graphics feature set, and support for ATIs famed AVIVO multimedia technology. Shader Model 3. and High Dynamic Range support is finally included, catching up to where NVIDIAs GeForce 6-series had already been quite a while ago. The X1600 GPU itself has support for almost any graphics RAM imaginable, from the antiquated DDR1 to the defacto standard GDDR3 towards the upcoming GDDR4, making this one robust GPU.
The MR X1600 features 12 pixel pipelines and 5 shader units, up from the 8 pixel pipelines and 4 shader units from the MR X700 it replaces. Perhaps the best part about this GPU is its thermal design power, or the amount of power that must be dissipated by the cooling system. The previous Mobility Radeon X700 was built on a 110nm manufacturing process, consumed a mere 14W, and was among the best GPU’s for a thin & light notebook; ATI’s greatest thin & light GPU by far. Thanks towards the X1600’s new 90nm manufacturing process, a new power management technique called Back Biasing, and the updated PowerPlay 6. power management software, the Mobility Radeon X1600 dissipates up to 17W! This is ATI’s very first mobile 12-pipeline GPU, so we can’t make a direct comparison there. However if we look at NVIDIA’s GeForce Go 6800, that GPU was manufactured on a 110nm process, has 12 pipelines, and has a TDP around 40W! The X1600 truly is an achievement in mobile thin & light gaming, offering very respectable performance in machines that may be still be considered portable! Obviously the Asus A7G is not one particular machines, but don’t be surprised to see the X1600 in 15.4″ machines and hopefully even smaller chassis!
An 8-cell battery is standard, featuring a capacity of 4800mAh rated at 71Whr with19V voltage. Battery life however was pretty dismal at around 2 hours, despite the respectable capacity. The reason for this is of course destined to be the giant and bright LCD panel. Still, we are a bit disappointed that a better battery life couldnt be achieved using stock settings. Our benchmarks are run with the power scheme set to Portable/Laptop for consistency, but Asus excellent Power4Gear software should allow for some extra juice from the A7G.
A little bit of an oddity to note here is that Asus places the battery at the front end of the machine, whereas any laptop has the battery located at the back. There is no real negative to this that we can tell, just an oddity to indicate.
It is difficult not to like the Asus A7G 17 multimedia notebook. The many key ingredients are there: top notch screen, good performance, a very decent GPU, along with a slick design to boot. Multimedia-centric users will appreciate the spacious, breathtaking display and loud speakers. In fact, this laptop would make a great coffee table center piece. The Asus screensaver included flashes some pretty graphics, plays a peppy tune, and even uses the onboard camera to display video amidst the swirling images. Even the more serious gamers shouldnt be put off by the A7G. ATIs new Mobility Radeon X1600 doesnt break any mobile graphics performance records, but it does play pretty much every game out there with very respectable performance while consuming very little power. Overall we have a well built, nicely performing notebook with a full set of multimedia features.
As you have seen from the Pros & Cons section, we dont have plenty of bad things to say about the A7G. However you may also see we dont have a lot of good things to say. We are satisfied with this notebook and particularly love the screen, but not a lot is really blowing our skirts up. Fujitsu offers a similar machine in their Lifebook models, which sport integrated TV tuners, similarly beautiful screens, and a number of multimedia features. In fact the Lifebooks offer Windows Media Center edition as an operating system, something the A7G does not offer. The current line of Lifebooks do not have anything impressive in the GPU category though, which will turn off gamers. The comparable Lifebook, model N6220, is similarly priced and has an Pentium M 750 (1.86GHz), 1GB DDR2 533 RAM, 17″ WXGA , 200GB dual difficult drives, Dual Layer DVDRW, TV Tuner, and Windows XP Media Center Edition. Unfortunately the GPU is only an ATI Mobility Radeon X600 with 256MB Hypermemory. The 200GB dual difficult drives are a bonus for a true multimedia enthuasiast, while the GPU is a bane for gamers. The differences in the two models are clearly between multimedia and gaming, which should make the choice easy for most consumers.
